Product features
1. Ultra-high imaging quality
2, support 5 million pixel camera
3, low illumination large aperture
4. TV distortion is less than 1%
5. The focus range is from 0.1M to infinity.
6. High relative illumination
| model | Maximum image plane | resolution ratio | focal length | aperture | viewing angle | TV distortion | Closest Distance | ||
| 2/3" | 1/2" | 1/3" | 2/3" | ||||||
| FA0802D | 2/3" | 5M | 8mm | 1.4~16 | 56.3°x43.7° | 42.5°x32.4° | 30.7°x23.8° | <1% | 0.1m、0.075X |
| FA1202D | 2/3" | 5M | 12mm | 1.4-16 | 39°x30.3° | 29.48°x22.8° | 21.3°x16.5° | <-0.8% | 0.15m、0.077X |
| FA1602D | 2/3" | 5M | 16mm | 1.4~16 | 30.3°x23° | 22.3°x16.8° | 16.8°x12.6° | <0.1% | 0.1m、0.145X |
| FA2502D | 2/3" | 5M | 25mm | 1.4~16 | 20°x15° | 14.6°x11° | 11°x8.2° | <0.2% | 0.1m、0.253X |
| FA3502D | 2/3" | 5M | 35mm | 1.4~16 | 13.9°x10.4° | 10.1°x7.6° | 7.6°x5.7° | <-0.8% | 0.15m、0.213X |
| FA5002D | 2/3" | 5M | 50mm | 1.4-C | 10.46°x7.86° | 7.6°x5.27° | 5.7°x4.3° | <-0.8% | 0.3m、0.177X |
